ROCK
Rugged, Off Road yet Luxurious Inside
The Avida Rock is an off road caravan, it is light weight and has a modern interior design that allows you to explore the remote parts of Australia in style.
There are a couple of layouts available; Choose to travel as just a couple, or with your mates or why not take the whole family with the bunk bed option?
GALLERY
Experience the Avida Rock caravan with our collection of exterior, interior and lifestyle images and videos.
GALLERY
Experience the Avida Rock caravan with our collection of exterior, interior and lifestyle images and videos.
FLOORPLANS
The Avida Rock caravan range includes 3 models with differing internal configurations.
FLOORPLANS
The Avida Rock caravan range includes 3 models with differing internal configurations.
3D TOURS
Experience the Avida Rock caravan with our virtual 3D tours from the comfort of your own home.
3D TOURS
Experience the Avida Rock caravan with our virtual 3D tours from the comfort of your own home.
**Please read: Due to continuous improvement, specifications are subject to change without notice. For more detailed information please contact your nearest dealer.
**Please read: Due to continuous improvement, specifications are subject to change without notice. For more detailed information please contact your nearest dealer.
SPECIFICATIONS & FEATURES
Built using Avida’s unique sandwich panel construction floor, walls and roof provides you with a strong caravan that is built to last.
The Rock range is an off road caravan. So if you like heading to remote areas this is the caravan for you.
| Model | Exterior Body Length | Exterior Width (inc. awning) | Interior Height | Axle Quantity |
|---|---|---|---|---|
| 20 Foot – 64 Series Layout | 6375mm | 2495mm | 2015mm | Tandem |
| Weights and Capacities | ||||
|---|---|---|---|---|
| Model | Travel Length | External Travel Height | Ball mass (empty) Approx.* | Tare weight Approx.* |
| CV6436BB2 | 8600mm | 3150mm | 195kg | 2585kg |
| CV6434 | 8600mm | 3150mm | 150kg | 2735kg |
* Note: The Tare and Ball weights in the table above are approximate only. Weights will vary depending on the options fitted at both factory and dealer. To find out more information consult your dealer.
| Air conditioner – 240V roof mounted reverse cycle |  |
| Avida’s unique, strong, highly insulated and light weight sandwich panel construction with underfloor protection | |
| Compliance – Certified weight certificate ex-factory with every vehicle | |
| Compliance – RVMAP industry accredited manufacturer (look for the accreditation key) | |
| Fridge – 188L 2 door automatic energy selection fridge / freezer | |
| Microwave – Carousel microwave | |
| Range hood – Stainless steel with fan & light | |
| Residential soft close drawers | |
| Solar – Solar panels with regulator | 300w (O-450w) |
| Stove – Recessed 4 burner LPG stainless steel stove cook top with gas griller combo & glass lid for extra bench space | |
| TV – with DVD Player, wind up TV antenna with signal booster | Smart TV |
| Washing machine | |
| Water – water tanks plumbed independently | 2 x 120L |
| Bathroom with shower, toilet & porcelain sink | |
| Battery | 2 x 100A |
| Battery – Integrated battery charger & power supply | |
| Battery – Integrated display & controller unit for water tank & battery management | |
| Battery – Additional battery | O |
| Battery – Wireless battery management through app | O |
| Bed – Lift up bed on gas struts for easy lifting with storage under bed | |
| Bed – Queen size 1,520mm width | |
| Cupboards – Modern contemporary super gloss finish with aluminium extrusion in overhead cabinets for strength | |
| Drawers – Metal runners plus large pots & pans storage | |
| Fridge – Compressor fridge | O |
| Handle free overhead cupboards | |
| Heating – Gas heater | O |
| Hot water system – 240V & gas system with 12V electric start | |
| Lighting – 12V LED lighting | |
| Lighting – LED mood lighting throughout | |
| Mattress – Multilayered memory comfort | |
| Mirror – Large mirror with lights over vanity | |
| Oven – Recessed 4 burner LPG stainless steel stove cook top with gas griller combo & glass lid for extra bench space and gas oven | O |
| Pantry – Slide out pantry | |
| Power – 12V & 240V power systems with 240V external GPO | |
| Roof hatch with 12V fan in bathroom | |
| Separate tap at sink with water filter | |
| Shower – Large separate shower with aluminium shower screen door |  |
| Stereo – With bluetooth, AUX & USB ports | |
| Storage – Ample storage throughout & under bed | |
| Table – Adjustable & removable swivel dining table | |
| Table – Tri-fold table | O |
| TV – Additional television with DVD player | O |
| TV – Satellite TV receiver | O |
| Upholstery – Fabric | O |
| Upholstery – Ultra Leather | |
| Upholstery – Leather | O |
| Water tank – Dual filling with control to separate your water storage | |
| Windows – Enormous dual pane flush mounted windows with fly screens and block out blinds | |
| Awning – Light(s) | |
| Awning – Quality roll out awning | |
| BBQ – External BBQ on slide | O |
| BBQ fitting – External | |
| Bike rack | O |
| Boot – Front boot storage | |
| Brush protection rails at floor level | |
| Checker plate – increased height side wall stone protection | |
| Coupling type – DO35 off road | |
| Entertainment unit – with radio speakers, table, 12V & 240V power and provisions for TV | |
| External slide out kitchen | O |
| Gas – 2 x 9kg gas bottles on A frame | |
| Handle – External grab handle with integrated LED light | |
| Jerry can provision | |
| Lighting – Front external working light | |
| Shower – External shower with hot and cold water | O |
| Spare wheel – Rear bumper mounted | |
| Step – Electric entry step | O |
| Step – Manual pull out entry step | |
| Stone guard on A frame | |
| Stone Protection – Premium stone guard protective coating on front or checker plating | |
| Suspension – Cruisemaster XT independent coil | |
| Tool box on draw bar with shelving and slide out trays | |
| Water – Grey water tank | 120L |
| Water tank stone guard | |
| Brakes – Electric brakes | |
| Breakaway system | |
| Earth leakage protector – 240V | |
| Entry door – Four point lock with security screen | |
| ESC – AL-KO electronic stability control (ESC) | O |
| Fire extinguisher | |
| LP gas leak detector | |
| Reverse camera | |
| Smoke detector | |
| Chassis – Revolutionary hot dipped galvanised chassis | |
| Corner steady – AL-KO corner steady stabilisers with foot pads | |
| Extended draw bar | |
| Jockey wheel – AL-KO 150mm centre mounted | |
| Plug – 12 Pin car / loom plug | |
| Stone Guard – External front mesh stone guard on draw bar | |
| Water – External tap on A frame | |
| Wheels – Machined sports alloy wheels including spare | 16″ |
